Power factor correction diesel generator set with reactive power compensation - Elitech Power

PFC Technology · Unity Power Factor · 20–30% More Usable Capacity · CE Certified

Power Factor Correction Diesel Generator
PFC & Reactive Power Compensation for Industrial Loads

Elitech Power's power factor correction (PFC) diesel generator sets integrate advanced solid-state control to maintain unity power factor, eliminate harmonics, and provide load balancing. Also known as capacitor compensated diesel generators or diesel generator sets with reactive power compensation. Ideal for telecom, data centres, industrial loads with poor power factor. Increase usable capacity by 20–30% without derating. Factory direct pricing with 24-hour quote response.

Get PFC Generator Quote

WhatsApp Now

View All PFC Models

PFC Diesel Generators %custom_field_Attribute 2 value(s)%

20–2000

kVA Range

Unity

Power Factor

20–30%

More Capacity

Certified

Technology Overview

What is a Power Factor Correction (PFC) Diesel Generator?

A power factor correction diesel generator integrates a pulse-width modulated voltage source converter (PWM-VSC) or DSTATCOM (Distribution Static Compensator) with the generator set. This solid-state compensator supplies the leading reactive power (kVAR) required by inductive loads, allowing the generator to operate at unity power factor.

Also known as capacitor compensated diesel generators or diesel generator sets with reactive power compensation, these units eliminate harmonics from source currents, provide load balancing, and improve voltage regulation. The result: full utilisation of generator rating without derating.

PFC Diesel Generator Specifications

Standard technical specifications for power factor correction diesel generator sets. Custom configurations available.

Power Range	20 kVA – 2,000 kVA (prime and standby ratings)
Power Factor (Generator)	Unity (1.0) – fully compensated regardless of load PF
Load Power Factor Range	0.6 lagging to 0.9 leading – fully compensated
Compensation Technology	PWM-VSC with DSP control / DSTATCOM
Harmonic Elimination	Meets IEEE 519 standards; THD < 5%
Engine Options	Cummins / Perkins / Yuchai / SDEC / Yanmar / Baudouin / Weichai
Alternator Options	Stamford / Leroy-Somer / Mecc Alte / Acelite
Voltage Output	400V / 230V standard; custom voltage available
Frequency	50Hz or 60Hz
Control System	Advanced DSP-based controller with VSS-FXLMS algorithm
Response Time	< 700 μs transient recovery
Enclosure Options	Open frame · Silent canopy · Containerized
Industry Synonyms	Diesel Generator Set with Reactive Power Compensation · Capacitor Compensated Diesel Generator · PFC Genset · Unity Power Factor Generator
Standards	ISO 8528, CE, IEEE 519, IEC 61000
Warranty	12 months (engine + compensator)

Why Power Factor Correction for Diesel Generators?

The economic and technical case for PFC diesel generator sets.

20–30% More Usable Capacity

Most inductive loads operate at 0.7–0.8 power factor, forcing generator derating of 20–30%. PFC allows full utilisation of generator rating – the compensator cost (typically 10% for >500kVA units) is recovered through increased capacity.

Harmonics Elimination

PWM-VSC compensator actively filters harmonics from source currents, preventing torque ripples on generator shaft, reducing fuel consumption, and extending generator life. Meets IEEE 519 standards.

Load Balancing & Voltage Regulation

Handles unbalanced and non-linear loads without degrading power quality. Compensator supplies reactive and harmonic components, improving voltage regulation at point of common coupling.

How It Works

Solid-State Reactive Power Compensation

System Configuration

The PFC diesel generator consists of a diesel engine-driven wound field synchronous generator connected to a three-leg PWM-VSC with a DC-link capacitor. The VSC is connected at the point of common coupling through an interfacing transformer and inductors.

Control Algorithm

A variable step size filter-x least mean square (VSS-FXLMS) algorithm estimates reference currents for VSC control. This provides fast convergence and superior transient performance compared to conventional LMS-based controllers.

The VSC supplies leading kVAR to loads, maintaining unity power factor of the DG set while eliminating harmonics and providing load balancing. Terminal voltage is controlled by field excitation; frequency by engine speed governor.

Common Applications for PFC Generators

Ideal for loads with poor power factor, harmonics, or unbalanced conditions.

Telecom Base Stations

Telecom loads often include rectifiers and switching supplies – highly non-linear with poor power factor. PFC gensets ensure unity PF operation and harmonic compliance.

Data Centres

UPS systems and server loads create significant reactive power demand. PFC generators eliminate the need for oversizing, providing full rated capacity.

Industrial Plants

Motor-driven equipment (pumps, compressors, conveyors) typically operates at 0.7–0.8 PF. PFC allows full utilisation of generator rating without derating.

Hospitals & Healthcare

Critical medical equipment with switching power supplies creates harmonics. PFC ensures clean power and optimal generator performance.

Remote Mining

Large motor loads and variable operating conditions benefit from PFC's load balancing and voltage regulation capabilities.

Isolated Microgrids

Standalone systems with mixed load types require robust power quality – PFC generators provide unity PF operation and harmonic mitigation.

PFC Diesel Generator FAQ

What is the difference between a standard diesel generator and a PFC diesel generator?

A standard diesel generator must be derated when supplying inductive loads (e.g., 0.8 PF load requires 20% derating). A PFC diesel generator integrates a solid-state compensator (PWM-VSC or DSTATCOM) that supplies the reactive power locally, allowing the generator to operate at unity power factor regardless of load PF. This means a 500kVA PFC generator can supply a 500kVA load even at 0.8 PF, whereas a standard unit would be limited to 400kVA.

What is the cost-benefit of a PFC generator versus standard unit with oversizing?

For a 500kVA unit, the power electronics compensator adds approximately 10% to the generator cost. However, it enables 20–30% more usable capacity – the additional capacity pays for the compensator while providing better power quality, harmonics elimination, and load balancing. For units above 500kVA, the economic case is even stronger.

Can PFC generators handle non-linear loads with harmonics?

Yes. The PWM-VSC compensator actively filters harmonics from source currents, preventing torque ripples on the generator shaft. The control algorithm (VSS-FXLMS) is specifically designed to extract and compensate harmonic components, achieving THD < 5% and meeting IEEE 519 standards.

What happens if the compensator fails? Can the generator still operate?

The compensator is connected at the point of common coupling and can be taken out of service without interrupting power supply. In such cases, the generator continues to operate as a standard unit but will require derating for reactive loads. For mission-critical applications, redundant compensator configurations are available.

What is the response time of the PFC system?

The VSC compensator has a transient recovery time of approximately 700 μs, ensuring seamless compensation during load changes. The high-speed DSP controller with VSS-FXLMS algorithm provides fast convergence and stable operation.
